Biomedical scientists invent shape-shifting nanomaterial with biogenic capabilities
Made of synthetic collagen, scientists from Emory University have developed a new nanomaterial that can trigger shape lift from sheets to tubes and back in a controllable fashion. The tool is claimed to have a range of biomedical applications, from controlled-release drug delivery to tissue engineering too.
The Journal of the American Chemical Society published a description of the nanomaterial which in sheet form is 10,000 times thinner than the width of a human hair, is made of synthetic collagen. Naturally, occurring collagen is the most abundant protein in humans, making the new material intrinsically biocompatible.
Vincent Conticello, senior author of the finding and Emory professor of biomolecular chemistry said, “ For the first time, we can convert it from sheets to tubes and back simply by varying the pH, or acid concentration, in its environment.”
The Emory Office of Technology Transfer has applied for a provisional patent for the nanomaterial.
Collagen is the main structural protein in the body’s connective tissue, such as cartilage, bones, tendons, ligaments, and skin. It is also abundant in blood vessels, the gut, muscles, and in other parts of the body.
Collagen taken from other mammals, such as pigs, is sometimes used for wound healing and other medical applications in humans. Conticello’s lab is one of only about a few dozen around the world focused on developing synthetic collagen suitable for applications in biomedicine and other complex technologies. Such synthetic designer biomaterials can be controlled in ways that natural collagen cannot.
“As far back as 30 years ago, it became possible to control the sequence of collagen. The field has really picked up steam, however, during the past 15 years due to advances in crystallography and electron microscopy, which allows us to better analyze structures at the nano-scale,” Conticello said.
The development of the new shape-shifting nanomaterial at Emory was ‘a fortuitous accident’ according to the researchers.
The collagen protein is composed of a triple helix of fibers that wrap around one another like a three-stranded rope. The strands are not flexible, they’re stiff like pencils, and they pack together tightly in a crystalline array.
The Conticello lab has been working with collagen sheets that it developed for a decade. “A sheet is one large, two-dimensional crystal, but because of the way the peptides pack it’s like a whole bunch of pencils bundled together,” Conticello explained. Half the pencils in the bundle have their leads pointing up and the other half have their eraser-end pointing up.
Conticello wanted to try to refine the collagen sheets so that each side would be limited to one functionality. To take the pencil analogy further, one surface of the sheet would be all lead points and the other surface would be all erasers. The ultimate goal was to develop collagen sheets that could be integrated with a medical device by making one surface compatible with the device and the other surface compatible with functional proteins in the body.
When the researchers engineered these separate types of surfaces into single collagen sheets, however, they were surprised to learn that it caused the sheets to curl up like scrolls. They then found that the shape-shifting transition was reversible -- they could control whether a sheet was flat or scrolled simply by changing the pH of the solution it was in. They also demonstrated that they could tune the sheets to shapeshift at particular pH levels in a way that could be controlled at the molecular level through design.
Conticello said, “That opens the potential to find a way to load a therapeutic into a collagen tube under controlled, laboratory conditions. The collagen tube could then be tuned to unfurl and release the drug molecules it contains after it enters the pH environment of a human cell.”
