Study finds how giraffes develop muscle control to outsmart predators
German researchers conducted a study to find out how animals learn to walk and learn from stumbling. They built a four-legged, dog-sized robot, that helped them figure out the details.
According to a study, the young giraffe or foal needs to develop its ability to move quickly on its legs in order to avoid predators. Animals' spinal cords contain networks for coordinating their muscles after birth. It takes some time to become proficient in the precise coordination of the tendons and muscles in the legs.
Infant animals rely substantially at first on hardwired spinal cord reflexes. While still relatively simpler, the animal's motor control reflexes enable it to walk without falling or injuring itself when it first tries.
The nervous system must then gradually adjust to the young animal's leg muscles and tendons through exercise with increasingly complex and precise muscle control. The juvenile animal can now keep up with the adults without slipping out of control.
The findings of the research were published in the journal Nature Machine Intelligence. Researchers at the Max Planck Institute for Intelligent Systems (MPI-IS) in Stuttgart conducted a research study to find out how animals learn to walk and learn from stumbling. They built a four-legged, dog-sized robot, that helped them figure out the details.
"As engineers and roboticists, we sought the answer by building a robot that features reflexes just like an animal and learns from mistakes," says Felix Ruppert, a former doctoral student in the Dynamic Locomotion research group at MPI-IS. "If an animal stumbles, is that a mistake? Not if it happens once. But if it stumbles frequently, it gives us a measure of how well the robot walks."
Felix Ruppert is first author of "Learning Plastic Matching of Robot Dynamics in Closed-loop Central Pattern Generators."
Also Read | World’s tallest animal, easily spotted in Africa, speeding towards extinction
Learning algorithm optimises virtual spinal cord
After learning to walk in just one hour, Ruppert's robot makes good use of its complex leg mechanics. A Bayesian optimization algorithm guides the learning: the measured foot sensor information is matched with target data from the modeled virtual spinal cord running as a program in the robot's computer. The robot learns to walk by continuously comparing sent and expected sensor information, running reflex loops, and adapting its motor control patterns.
The learning algorithm adapts control parameters of a Central Pattern Generator (CPG). In humans and animals, these central pattern generators are networks of neurons in the spinal cord that produce periodic muscle contractions without input from the brain.
Central pattern generator networks aid the generation of rhythmic tasks such as walking, blinking or digestion. Furthermore, reflexes are involuntary motor control actions triggered by hard-coded neural pathways that connect sensors in the leg with the spinal cord.
As long as the young animal walks over a perfectly flat surface, CPGs can be sufficient to control the movement signals from the spinal cord. A small bump on the ground, however, changes the walk. Reflexes kick in and adjust the movement patterns to keep the animal from falling.
These momentary changes in the movement signals are reversible, or 'elastic', and the movement patterns return to their original configuration after the disturbance. But if the animal does not stop stumbling over many cycles of movement -- despite active reflexes -- then the movement patterns must be relearned and made 'plastic', i.e., irreversible.
In the newborn animal, CPGs are initially not yet adjusted well enough and the animal stumbles around, both on even or uneven terrain. But the animal rapidly learns how its CPGs and reflexes control leg muscles and tendons.
The same holds true for the Labrador-sized robot-dog named "Morti." Even more, the robot optimizes its movement patterns faster than an animal, in about one hour. Morti's CPG is simulated on a small and lightweight computer that controls the motion of the robot's legs. This virtual spinal cord is placed on the quadruped robot's back where the head would be.
During the hour it takes for the robot to walk smoothly, sensor data from the robot's feet are continuously compared with the expected touch-down predicted by the robot's CPG. If the robot stumbles, the learning algorithm changes how far the legs swing back and forth, how fast the legs swing, and how long a leg is on the ground. The adjusted motion also affects how well the robot can utilize its compliant leg mechanics.
During the learning process, the CPG sends adapted motor signals so that the robot henceforth stumbles less and optimizes its walking. In this framework, the virtual spinal cord has no explicit knowledge about the robot's leg design, its motors and springs. Knowing nothing about the physics of the machine, it lacks a robot 'model'.
"Our robot is practically 'born' knowing nothing about its leg anatomy or how they work," Ruppert explains. "The CPG resembles a built-in automatic walking intelligence that nature provides and that we have transferred to the robot. The computer produces signals that control the legs' motors, and the robot initially walks and stumbles. Data flows back from the sensors to the virtual spinal cord where sensor and CPG data are compared.
If the sensor data does not match the expected data, the learning algorithm changes the walking behaviour until the robot walks well, and without stumbling. Changing the CPG output while keeping reflexes active and monitoring the robot stumbling is a core part of the learning process."
Energy-efficient robot dog control
Morti's computer draws only five watts of power in the process of walking. Industrial quadruped robots from prominent manufacturers, which have learned to run with the help of complex controllers, are much more power hungry. Their controllers are coded with the knowledge of the robot's exact mass and body geometry -- using a model of the robot.
They typically draw several tens, up to several hundred watts of power. Both robot types run dynamically and efficiently, but the computational energy consumption is far lower in the Stuttgart model. It also provides important insights into animal anatomy.
"We can't easily research the spinal cord of a living animal. But we can model one in the robot," says Alexander Badri-Sprowitz, who co-authored the publication with Ruppert and heads the Dynamic Locomotion Research Group. "We know that these CPGs exist in many animals. We know that reflexes are embedded; but how can we combine both so that animals learn movements with reflexes and CPGs? This is fundamental research at the intersection between robotics and biology. The robotic model gives us answers to questions that biology alone can't answer."
